尺寸 | 31.5" |
分辨率 | 1920 X 1080 (16 : 9) |
像素间距 | 0.364mm |
色深 | 16.7M |
可视角度 | 178°(H) / 178°(V) |
亮度 | 400cd/m 2 |
对比度 | 1200 : 1 |
显示范围 | 698(H) x 392(V) mm |
3 X BNC | Analog Input |
2 X BNC | 3G-SDI A/B Channel Input |
1 X HDMI | HDMI Input |
1 X DVI | DVI Input |
3 X BNC | Analog Output |
1 X BNC | 3G-SDI Output |
Audio In | Embedded Audio/Analog Stereo (Phone Jack) |
Audio Out | Analog Stereo (Phone Jack) |
1:1 Pixel Mapping Modes for SD/HD, Blue Only, H/V Delay, Key Lock, Marker, Mono, Range Error, Time Code Display, UMD, User Aspect, Waveform/Vector |
CC-608 ANC, CC-608 LINE 21, CC-708, CC-KOR, OP42, OP47 |
TVLogic Color Calibration Utility |
REMOTE | GPI (RJ45) |
REMOTE | TVLogic’s specification |
USB | Firmware update by USB cable |
Ethernet | Ethernet Control support |
Conversion | SDI-to-SDI |
Carrying Case |
